.ThermofluidStream.Processes.Pipes

Information

Package containing basic piping components, such as pipes, bends and topolgy components.

[P. Jordan; HTWG Konstanz; 03/24]

Contents

Name	Description
UsersGuide	User's Guide
CurvedBend	Pressure drop due to curved bend using Modelica.Fluid.Dissipation.PressureLoss.Bend
EdgedBend	Pressure drop due to edged bend using Modelica.Fluid.Dissipation.PressureLoss.Bend
SuddenExpansion	Pressure drop due to expansion using Modelica.Fluid.Dissipation.PressureLoss.Orifice
SuddenContraction	Pressure drop due to contraction using Modelica.Fluid.Dissipation.PressureLoss.Orifice
EdgedOrifice	Pressure drop due to sharp edged orifice using Modelica.Fluid.Dissipation.PressureLoss.Orifice
Diffuser	Pressure drop of a conical diffusor
SplitterY	Pressure drop of an Y-shaped splitter
JunctionY	Pressure drop of an Y-shaped junction
Internal
Tests
Interfaces
BaseClasses
