modelForcedSplitting_nonPhysical
Forced splitting using non-physical equations
Extends from Modelica.Icons.Example (Icon for runnable examples).
Information

Components
| Type | Name | Default | Description |
|---|---|---|---|
| Components.MIMO.ForcedSplitting_nonPhysical | splitter | ||
| Sources.MassFlowBoundary_h | massFlowBoundary | ||
| Sources.PressureBoundary_h | pressureBoundary_b | ||
| Sources.PressureBoundary_h | pressureBoundary_c | ||
| Modelica.Blocks.Sources.Ramp | ramp |
