.Buildings.DHC.Loads.BaseClasses.PartialBuilding

Information

Partial model to be used for modeling the thermal loads on an energy transfer station or a dedicated plant. Models extending this class are typically used in conjunction with Buildings.DHC.Loads.BaseClasses.FlowDistribution and models extending Buildings.DHC.Loads.BaseClasses.PartialTerminalUnit as described in the schematics here under. The fluid ports represent the connection between the production system and the building distribution system.

Scaling

Scaling is implemented by means of a multiplier factor facMul. Each extensive quantity (mass and heat flow rate, electric power) flowing out through fluid ports, or connected to an output connector is multiplied by facMul. Each extensive quantity (mass and heat flow rate, electric power) flowing in through fluid ports, or connected to an input connector is multiplied by 1/facMul. This allows modeling, with a single instance, multiple identical buildings served by the same energy transfer station.

Examples

See various use cases in Buildings.DHC.Loads.BaseClasses.Examples.

Contents

Name	Description
Medium	Medium in the building distribution system

Revisions

• December 21, 2020, by Antoine Gautier:
  Added multiplier factor.
  This is for issue 2291.
• February 21, 2020, by Antoine Gautier:
  First implementation.
